Buy Ubiquiti UniFI AP Outdoor+ Wi-Fi 802.11 b/g/n, 2.4 GHz
Ubiquiti UniFI AP Outdoor+ Wi-Fi 802.11 b/g/n is a robust, high-performance outdoor Wi-Fi access point designed to provide extended-range wireless coverage.
Quick Specifications
- Networking Interface: (2) 10/100 Ethernet Ports, Buttons: Reset.
- Antennas: (2) External 5 dBi Omni Antennas Included 191 mm (Length), 13 mm (Diameter), Wi-Fi Standards: 802.11 b/g/n.
- Power Method: Passive Power over Ethernet (48V), 802.3af Supported.
- Power Supply: 48V, 0.5A PoE Adapter (Included), Maximum Power Consumption: 8 W.
- Maximum TX Power: 28 dBm, Wireless Security: WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES), Operating Temperature: -30 to 65° C (-22 to 149° F).
| General | |
| Networking Interface | 2 x 10/100 Ethernet ports |
| Button | Reset |
| Antennas | 2 x External 6 dBi omni antennas (included) Length: 7.5″ (191.0 mm) Diameter: 0.5″ (13.0 mm) |
| Power Method | 12 to 24 V PoE |
| Power Supply | 24 V, 1 A PoE adapter (included) |
| Maximum Power Consumption | 6.5 W |
| Maximum TX Power | 27 dBm |
| BSSID | Up to 4 per radio |
| Power Saving | Supported |
| Wireless Security | WEP, WPA-PSK, WPA-TKIP, WPA2 AES, 802.11i |
| Mounting | Wall and pole (kits included) |
| Advanced Traffic Management | |
| VLAN | 802.1Q |
| Advanced QoS | Per-user rate limiting |
| Guest Traffic Isolation | Supported |
| WMM (Wi-Fi Multimedia) | Voice, video, best effort, and background |
| Concurrent Clients | 100+ |
| Environmental | |
| Operating Temperature | -22 to 167°F (-30 to 75°C) |
| Operating Humidity | 5 to 95% (non-condensing) |
| Supported Data Rates | 802.11a: 6, 9, 12, 18, 24, 36, 48, 54Mb/s 802.11n: 6.5 to 300 Mb/s (MCS0 – MCS15, HT 20/40) |
| Standards and Certifications | |
| Certifications | CE, FCC, IC |
| Physical Characteristics | |
| Dimensions | 6.69 x 3.15 x 1.18″ (170.00 x 80.00 x 30.00 mm) |
| Weight | Without Antennas: 8.11 oz (230.00 g) With Antennas: 9.67 oz (274.00 g) |
| Packaging Info | |
| Package Weight | 1.7 lb |
| Box Dimensions (LxWxH) | 9.0 x 7.5 x 3.4″ |
Outdoor 802.11n Access Point
Featuring Wi-Fi 802.11n, the UniFi® AP-Outdoor is ideal for outdoor deployment. The UniFi AP-Outdoor+ model operates in the 2.4 GHz radio band, and the UniFi AP-Outdoor5 model operates in the 5 GHz radio band.
- 802.11 a/b/g/n Wi-Fi Standards
- Range of up to 600′
- 2 x 10/100 Ethernet Ports
- UniFi Controller Software
- 2 x External 5 dBi Omni Antennas
- Guest Portal/Hotspot Support
- Passive Power over Ethernet
- 100+ Concurrent Clients
- Reset Button
- CE, FCC, IC Certified
- UAP-Outdoor+
