Ubiquiti Networks RM5-Ti RocketM5 Titanium 2×2 MIMO airMAX BaseStation
Original price was: KSh32,000.00.KSh30,000.00Current price is: KSh30,000.00. + VAT
Buy Ubiquiti Networks RM5-Ti RocketM5 Titanium 2×2 MIMO airMAX BaseStation from Hubtechshop, Nairobi Kenya.
Quick product specs:
- TDMA airMAX Protocol
- Integrated Ubiquiti airSync Technology
- Atheros MIPS 74KC, 550 MHz Processor
- 30+ Miles Range and 150+ Mb/s Speed
Buy Ubiquiti Networks RM5-Ti RocketM5 Titanium 2×2 MIMO airMAX BaseStation
Ubiquiti Networks RM5-Ti RocketM5 Description;
The Ubiquiti Networks RM5-Ti RocketM5 Titanium 2×2 MIMO airMAX BaseStationfeatures enhanced radio performance and superior durability. Its carrier-class capabilities link distances up to 30+ miles and provide speeds of up to 150+ Mb/s. The RocketM Titanium features Gigabit Ethernet connection to deliver high throughput for reliable data transfers. The RocketM Titanium enclosure is designed to improve performance in harsh RF environments and in extreme weather conditions. Enclosed in aircraft-grade aluminum, the RocketM Titanium is a rugged, high-power, linear 2×2 MIMO radio.
RocketM5 Titanium has an integrated Ubiquiti airSync technology. airSync enhances the hardware and software of the Rocket to utilize GPS signals for precision timing. airOS is upgraded for the GPS hardware in the RocketM5 Titanium. You can easily manage and monitor GPS satellite signals. Synchronized transmission among RocketM5 Titanium BaseStations effectively eliminates co-location interference.
The RocketM Titanium may be deployed in PtP bridging or PtMP airMAX BaseStation applications. It can be paired with your choice of airMAX BaseStation Sector or RocketDish antennas. This versatility gives network architects unparalleled flexibility and convenience. Ubiquiti’s Time Division Multiple Access (TDMA) airMAX protocol allows each client to send and receive data using pre-designated time slots, scheduled by an intelligent AP controller.
Quick product specs:
- TDMA airMAX Protocol
- Integrated Ubiquiti airSync Technology
- Atheros MIPS 74KC, 550 MHz Processor
- 30+ Miles Range and 150+ Mb/s Speed
GPS Synchronization
RocketM5 Titanium has an integrated Ubiquiti airSync technology. airSync enhances the hardware and software of the Rocket to utilize GPS signals for precision timing.
GPS Signal Reporting
airOS is upgraded for the new GPS hardware in the RocketM5 Titanium. You can easily manage and monitor GPS satellite signals.
No Co-Location Interference
Synchronized transmission among RocketM5 Titanium BaseStations effectively eliminates co-location interference.
External GPS Antenna
The RocketM5 Titanium includes a weatherproof, external GPS antenna.
airMAX Technology
Ubiquiti’s Time Division Multiple Access (TDMA) airMAX protocol allows each client to send and receive data using pre-designated time slots, scheduled by an intelligent AP controller. This “time slot” method eliminates hidden node collisions and maximizes airtime efficiency. It significantly improves performance in throughput, reduces latency, and increases scalability. With Intelligent QoS, priority is given to voice or video for seamless streaming. It is capable of high-speed links up to 50+ km. Its multiple features reduce noise.
Easy Installation
The RocketM Titanium and airMAX antennas have been designed to seamlessly work together. Installing the RocketM Titanium on an airMAX BaseStation sector or RocketDish antenna requires no special tools. You simply snap it securely into place with the universal Rocket mount built into the antenna.
Software
airOS
airOS is a versatile Ubiquiti firmware technology. It is an intuitive and user-friendly software that requires no training to operate. Behind the user interface is a powerful firmware architecture that enables high performance and outdoor multi-point networking. It features channel shifting, spectral width adjustment, ACK auto-timing, AAP technology, DHCP relay, protocol support, multiple VLAN support, and multi-language support.
airView
airView provides advanced spectrum analyzer functionality. Waterfall (aggregate energy over time for each frequency), waveform (aggregate energy collected), and real-time (energy is shown in real time as a function of frequency) spectral views allow operators to identify noise signatures and plan networks to minimize noise interference. You can also automate airView to record and report results.
airControl
airControl is a powerful and intuitive, Web-based server network management application that allows operators to centrally manage entire networks of Ubiquiti devices. It features Network map, monitor device status, mass firmware upgrade, Web UI access, manage groups of devices, and task scheduling.
In the Box
Ubiquiti Networks RM5-Ti RocketM5 Titanium 2×2 MIMO airMAX BaseStation
Gigabit PoE Adapter (48V, 0.5A)
Power Cord
Metal Strap
GPS Patch Antenna
Ubiquiti Networks RM5-TI Specs
Performance | |
|---|---|
Processor | Atheros MIPS 74KC, 550 MHz |
Memory | SDRAM: 128 MBFlash: 8 MB |
RF Connections | 2 x RP-SMA (waterproof )1 x SMA (GPS) |
Enclosure | Die-cast aluminum |
Networking Interface | 1 x 10/100/1000 Ethernet port1 x 10/100 Ethernet port |
Protection | ESD/EMP: 30 KV contact/air for Ethernet |
Operating Frequency | 5170 to 5825 MHz |
Range | 30.0+ miles (50+ km) (outdoor – antenna dependent) |
Output Power | 27 dBm |
TX Power Specifications | Modulation: 11 gData Rate: 6 to 24 Mb/sAverage TX: 27 dBmTolerance: ± 2 dBModulation: 11 gData Rate: 36 Mb/sAverage TX: 25 dBmTolerance: ± 2 dBModulation: 11 gData Rate: 48 Mb/sAverage TX: 23 dBmTolerance: ± 2 dBModulation: 11 gData Rate: 54 Mb/sAverage TX: 22 dBmTolerance: ± 2 dBModulation: 11n/airMAXData Rate: MCS0Average TX: 27 dBmTolerance: ± 2 dBModulation: 11n/airMAX |
RX Power Specifications | Modulation: 11 g Data Rate: 6 to 24 Mb/s Sensitivity: -94 dBm min. Tolerance: ± 2 dBModulation: 11 g Data Rate: 36 Mb/s Sensitivity: -80 dBm Tolerance: ± 2 dBModulation: 11 g Data Rate: 48 Mb/s Sensitivity: -77 dBm Tolerance: ± 2 dBModulation: 11 g Data Rate: 54 Mb/s Sensitivity: -75 dBm Tolerance: ± 2 dBModulation: 11n/airMAX Data Rate: MCS0 Sensitivity: -96 dBm Tolerance: ± 2 dBModulation: 11n/airMAX Data Rate: MCS1 Sensitivity: -95 dBm Tolerance: ± 2 dBModulation: 11n/airMAX Data Rate: MCS2 Sensitivity: -92 dBm Tolerance: ± 2 dBModulation: 11n/airMAX Data Rate: MCS3 Sensitivity: -90 dBm Tolerance: ± 2 dBModulation: 11n/airMAX Data Rate: MCS4 Sensitivity: -86 dBm Tolerance: ± 2 dBModulation: 11n/airMAX Data Rate: MCS5 Sensitivity: -83 dBm Tolerance: ± 2 dB Modulation: 11n/airMAX Modulation: 11n/airMAX Modulation: 11n/airMAX Modulation: 11n/airMAX Modulation: 11n/airMAX Modulation: 11n/airMAX Modulation: 11n/airMAX Modulation: 11n/airMAX Modulation: 11n/airMAX Modulation: 11n/airMAX |
Software | |
|---|---|
| Modes | Station, access point, AP repeater |
| Services | SNMP, DHCP, NAT |
| Utilities | Site survey with preferred SSID Antenna Alignment Tool Discovery utility |
| Security | WEP/WPA/WPA2 |
| QoS | 802.11e/WMM support |
| Statistical Reporting | Ethernet activity Uptime Packet success/errors |
Power | |
|---|---|
| Power Consumption | Maximum: 8 W |
| Power Supply | 48 V, 0.5 A PoE adapter (included) |
| Power Method | 802.3af compliant |
| Shock and Vibration | ETSI300-019-1.4 |
General | |
|---|---|
| LED Indicators | System: Power, WAN, LAN, and GPS Antenna Align/Signal Strength: Software adjustable to correspond to custom signal strength levels |
| Regulatory Compliance | Wireless Approvals: FCC Part 15.247, IC RS210, CE RoHS |
| Temperature | Operating: -22.0 to 167.0°F (-30.0 to 75.0°C) |
| Humidity | Operating: 5 to 95% condensing |
| Dimensions | 6.3 x 3.1 x 1.7″ (160.0 x 80.0 x 44.0 mm) |
| Weight | 12.3 oz (350.0 g) |
Packaging Info | |
|---|---|
| Package Weight | 1.95 lb |
| Box Dimensions (LxWxH) | 9.2 x 5.1 x 3.3″ |
