Tp-Link TL-SF1008P 8-Port 10/100mbps Desktop Switch With 4-Port Poe
Tp-Link TL-SF1008P 8-Port With 4-Port POE with 4-Port PoE is an 8 10/100Mbps ports unmanaged switch that requires no configuration and provides 4 PoE (Power over Ethernet) ports.
With 4 Poe Ports, Transfers Data & Power On 1 Single Cable
Working With Ieee 802.3af Compliant Pds, Expands Home & Office Network
2k Entry Mac Address Table Of The Tl-sf1008p With Auto-learning & Auto-aging
Requires No Configuration & Installation
It can automatically detect and supply power with all IEEE 802.3af-compliant Powered Devices (PDs). In this situation, the electrical power is transmitted along with data in one single cable allowing you to expand your network to where there are no power lines or outlets, where you wish to fix devices such as APs, IP cameras or IP phones, etc.

HARDWARE FEATURES for Tplink 8-Port 10/100Mbps Desktop Switch with 4-Port PoE TL-SF1008P | |
---|---|
Interface | 8 10/100Mbps RJ45 Ports AUTO Negotiation/AUTO MDI/MDIX |
Network Media | 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 100BASE-TX: UTP category 5, 5e cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) |
Fan Quantity | Fanless |
Power Consumption | Maximum (PoE on): 60.2W (220V/50Hz) Maximum (PoE off): 3.2W (220V/50Hz) |
External Power Supply | External Power Adapter(Output: 48VDC / 1.25A) |
PoE Ports (RJ45) | Standard: 802.3 af compliant PoE Ports: Port1- Port4 Power Supply: 57W |
Backbound Bandwidth | 1.6Gbps |
Mac Address Table | 2K |
Dimensions ( W x D x H ) | 6.7*3.9*1.1 in. (171*98*27 mm) |
SOFTWARE FEATURES | |
---|---|
Transmission Method | Store-And-Forward |
Advanced Functions | Compatible With IEEE 802.3af Compliant PDs Priority Function Mac Address Auto-Learning And Auto-Aging IEEE802.3x Flow Control For Full-Duplex Mode And Backpressure For Half-Duplex Mode |
OTHERS | |
---|---|
Certification | FCC, CE, RoHS |
Package Contents | TL-SF1008P, Power Adapter, User Guide |
Consumption | 2.3 watts (max. no PD connected) 59.3 watts (max. with 57w PD connected) |
Environment | Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
