SPECIFICATIONS

• 4 Pairs Unshielded Twisted Pair (UTP) Cable
• Conductor Metal: Bare Copper
• Color Code: Gray
• Conductor: 24 AWG
• Insulation Material: HD-PE
• Jacket Material: PVC UL94V-0
• Heat-resistant: 60oC minimum (Temperature limited)
• Flame property: The purpose of the
  vertical flame test is to screen out
  flammable wires. It follows the
  VW-1 (UL); FT-1 (CSA) standards.

MODULAR CONNECTOR/PLUG

• RJ-45 8P for Transparence color.
• Gold plated: 30U”
• Contact blade: Phosphor Bronze
• Temperature range: -10 ~ 80o C
• Dielectric withstanding voltage: 500V AC
• Insulation resistance: 35M Ohm (max.)
• Durability: 750 matching cycles
• Cable-to-plug tensile strength: 20lbs (89N) (min.)
• UL applications: 250V AC, 2A (max.)
• Polycarbonate (PC) UL94-V-0

Key Features:

1. Cat6 UTP Cable:
   • Constructed with Cat6 UTP cable, providing enhanced performance and bandwidth for high-speed data transmission within a local network.
2. 24 AWG Wire Gauge:
   • Utilizes 24 AWG (American Wire Gauge) copper conductors, ensuring efficient data transmission and compliance with Cat6 standards.
3. PVC Jacket:
   • Durable PVC (Polyvinyl Chloride) jacket provides protection to the cable and enhances its longevity, making it suitable for various installation environments.
4. Round Patch Cord Design:
   • Features a round patch cord design, offering flexibility and ease of installation in networking racks, cabinets, and other configurations.
5. 3-Meter Length:
   • Convenient 3-meter length, providing flexibility in connecting devices within moderate distances in networking setups.
6. Unshielded Twisted Pair (UTP):
   • UTP construction minimizes electromagnetic interference, making it suitable for general networking applications in both residential and commercial settings.
7. Enhanced Performance:
   • Meets or exceeds Cat6 performance standards, ensuring reliable and efficient data transmission for applications such as streaming, online gaming, and large file transfers.
8. Snagless Design:
   • Snagless design on both ends helps protect the connectors from damage during installation and ensures a secure and reliable connection
